感光元件

1.0"-type MOS 感光元件

有效像素

UHD: 8.59 MP
FHD: 17.78 MP

液晶監視器

3.5 type LCD 彩色液晶顯示器, Approx. 1,150,000 dots

快門

快門速度

59.94 Hz
60i/p Mode: 1/60, 1/100, 1/120, 1/180, 1/250, 1/350, 1/500, 1/750, 1/1000, 1/1500, 1/2000, 1/3000, 1/4000, 1/8000 second
30p Mode: 1/30, 1/50, 1/60, 1/100, 1/120, 1/180, 1/250, 1/350, 1/500, 1/750, 1/1000, 1/1500, 1/2000, 1/3000, 1/4000, 1/8000 second
24p Mode: 1/24, 1/48, 1/50, 1/60, 1/100, 1/120, 1/180, 1/250, 1/350, 1/500, 1/750, 1/1000, 1/1500, 1/2000, 1/3000, 1/4000, 1/8000 second

慢速快門

59.94 Hz
60i/60p Mode: 1/2, 1/4, 1/8, 1/15, 1/30 second
30p Mode: 1/2, 1/4, 1/8, 1/15 second
24p Mode: 1/2, 1/4, 1/6, 1/12 second

同步掃描速度

59.94 Hz
60i/p mode: 1/60.0 to 1/249.7 second
30p mode: 1/30.0 to 1/249.7 second
24p mode: 1/24.0 to 1/249.7 second

50.00 Hz
50i/p mode: 1/50.0 to 1/250.0 second
25p mode: 1/25.0 to 1/250.0 second

鏡頭

20x optical zoom 光學 20 倍 變焦
Focal Length: 8.8 to 176mm
35mm Equivalent
DCI 4K: 24 to 480mm
UHD: 25.4 to 508mm

記錄媒體

2 x SDHC/SDXC

輸入/輸出

Vicdeo --------------------------------------------------------------

Output

1 x HDMI Type A (VIERA Link not supported)
2160p 59.94/50/29.97/25/24/23.98
1080i 59.94/50
720p 59.94/50
480p 59.94
AV: 1 x Connector

Audio --------------------------------------------------------------

Input
High Impedance: Line/Mic/Mic +48 V (switchable SW)
Line: +4 dBu/0 dBu (switchable menu)
Mic: −40 / -50 / -60 dBu (switchable menu)

Output
HDMI: 2 ch (LPCM)
Audio Out: 1 x AV connector,
Output level: 600 Ohms, 316 mV
Headphone: 1 x 3.5 mm diameter, stereo mini jack
Speaker: 1 x 20 mm diameter

--------------------------------------------------------------------

Timecode
I/O: 1 x BNC
Input: 1.0 V to 4.0 Vpp, 10 KOhms
Output: 2.0 V ± 0.5 Vpp, low impedance

USB 3.0 Host
Standard-A connector, 9-pin, external media device connection, bus power supported

USB 3.0 Device
Micro-B connector, 10-pin, mass storage function (read-only)

DC In
12 VDC (11.4 to 12.6 V) EIAJ Type4

16.9 x 19.5 x 34.0 公分

重量

機身約 4.2 lb / 1.9 kg不含電池與配件

操作環境溫度 0˚C - 40˚C
操作環境濕度 10% to 80% (無結露)

電源

7.28 VDC via battery 電池
12 VDC via AC adapter 變壓器

12.2 W [ {LCD monitor 顯示開啓時 ]
