• Encoding Full NDI real-time stream at up to 4096x2160 60fps 4:2:2 8-bit
• Output the same resolution as input or any custom resolution. Typical outputs include:
  • 4096x2160p/3840x2160p/2048x1080p/1920x1080p 23.98/24/25/29.97/30/47.95/48/50/59.94/60
  • 2048x1080i/1920x1080i 25/29.97/30/47.95/48/50/59.94/60
  • 1280x720p 50/59.94/60
• Output frame rate same as the original, 1/2, 1/3 or 1/4 of input frame rate
• Encoding 16-channel NDI-embedded audio
• Support NDI 5.x

• Register with Control Hub
• Remote control via WebUI and Control Hub
• Provide comprehensive information regarding the device and signals in real-time
• Allow to configure how an input is processed and encoded, including deinterlacing, up/down scaling, frame rate, aspect ratio, as well as the network connection
• Update firmware
• Support USB RNDIS/ECM
• Support IE/Edge/Firefox/Chrome/Safari/Opera web browsers
• Provide HTTP APIs

Control PTZ cameras using protocols of VISCA, Visca UDP, Visca UDP2rs232, PELCO-P and PELCO-D via NDI

Mini-DIN–8 jack (shared with Tally light)

10/100/1000Mbps Ethernet

IEEE 802.3af PoE

USB2.0 Type B

5V/2.1A power supply

USB RNDIS/ECM

NDI Studio Monitor

OBS

vMix

Any other NDI-enabled product

tatus LEDs indicate:

Power supply: on/off

Tally: preview/program

Input signal: locked/unlocked

Loop through signal: on/off

USB 2.0 A to B cable

5V/2.1A power adaptor

Mini-DIN 8 breakout cable

Tally light

L-bracket<

¼–20 threaded hole

5V max current: ~1.65A

Max power consumption: ~8.5W

Operating temperature: 0 to 45 deg C

Storage temperature: –20 to 70 deg C

Relative humidity: 5% to 90% non-condensing
